TECHNICAL CHARACTERISTICS
- Capacity from 365 kg / 805 lb to 1000 kg / 2205 lb.
- Slewing platform +/- 90° on both sides.
- Safe: front opening only when a direct contact is made with the roof + can be moved only if the front part is closed.
- Legally approved for 3 persons.
- Presence sensor forbidding any movement after door opening.
- Overload sensor.
- Physical sensor allowing door opening only if roof contact.
- Number of people: 3.
- Distance to center of gravity: 1493 mm or 1300 mm depending on version.
- Overall weight: 1310 kg / 1210 kg / 920 kg / 990 kg depending on version.
- Overall height: 1614 mm or 1954 mm depending on version.
- Overall length: 2920 mm or 2605 mm depending on version.
- Width minimum: 2420 mm.
- Width maximum: 3682 mm.
- Depth: 1260 mm or 1218 mm depending on version.
- Rotation 1: 90° (depending on version).
- Rotation 2: 90° (depending on version).
CUSTOMER BENEFITS
- Cutting edge platforms designed for roof work.
- Secured platform.
- Non-slip metal flooring.
- Heavy duty and galvanised structure for an improved longevity.
- Platform NC: large 3,5 m / 11 ft working width.
- Roomy platform: can lift a pallet (Euro) even when folded.
COMPATIBILITY
Compatibility depends on machine model, series and configuration.
Please review the official technical documentation before purchase.
