Manitou 200 ATJ E 4WS

Manitou 200 ATJ E 4WS
Manitou 200 ATJ E 4WS - Image 2
Manitou 200 ATJ E 4WS - Image 3
Manitou 200 ATJ E 4WS - Image 4
Manitou 200 ATJ E 4WS - Image 5

Manitou 200 ATJ E 4WS

Call for price


Download Technical Sheet ↓

Working height: 20 m Maximum outreach: 11.57 m
Overhang: 7.91 m Platform capacity: 250 kg

The Manitou 200 ATJ e 4WS is a 100% electric articulated boom lift designed for powerful, zero-emission performance. With a 20 m working height, 11.57 m outreach, and 250 kg platform capacity, it provides safe access to demanding areas. Its 4-wheel drive and steering, high ground clearance, and oscillating axle ensure stability on rough terrain, while electric operation makes it ideal for both outdoor and indoor applications.

Categories: ,

Technical Sheet – 200 ATJ E 4WS

Powertrain: Electric

Max. Capacity 250 kg
Max. Lifting Height 18 m
Maximum Outreach 11.57 m
Turret Rotation 350 °
Hydraulic Flow 24 l
Max. Travel Speed 5.30 km/h
Operating Weight 7530 kg
Standard Tires Foam Filled Non Marking
Stabilizers Type Oscillating front axle
Transmission 4 wheel drive
Drive Motor Power (kW) N/A
Battery Technology Lead acid batteries
Battery Energy (kWh) 22 kWh
Battery Nominal Voltage (V) 48 V
