Manitou 220 TJ ST5

Manitou 220 TJ ST5
Manitou 220 TJ ST5 - Image 2
Manitou 220 TJ ST5 - Image 3
Manitou 220 TJ ST5 - Image 4
Manitou 220 TJ ST5 - Image 5

Manitou 220 TJ ST5

Call for price


Download Technical Sheet ↓

Working height: 21.77 m Maximum outreach: 17.63 m
Steering wheels (front): 2 Platform capacity: 230 kg

The Manitou 220 TJ ST5 is a high-performance telescopic boom lift built for demanding work at height. With a 21.77 m working height and an impressive 17.63 m outreach, it provides extended horizontal reach for maximum productivity. The 230 kg platform capacity safely supports two operators, while its robust design and all-terrain capability ensure stability and reliability on construction and industrial job sites.

Category:

Technical Sheet – 220 TJ ST5

Powertrain: Diesel

Max. Capacity 230 kg
Max. Lifting Height 19.77 m
Maximum Outreach 17.63 m
Turret Rotation 360 °
Hydraulic Flow 94 l
Max. Travel Speed 4.40 km/h
Operating Weight 12000 kg
Standard Tires Solid tires
Stabilizers Type Oscillating front axle
Transmission 4 wheel drive
Tank Capacities Fuel: 76 l
Engine Brand Yanmar – 3TNV88C
Engine Power (Hp / kW) 37 Hp / 27.50 kW
Engine Norm / Emission Stage V
